PreSonus CDL10P Active Array Module 10″

Description

10″ Active Line Array module with 2000 W peak that lets you build scalable systems without losing directivity or fidelity. Ideal for medium-range touring or permanent systems where you need controlled coverage, flat response and integrated rigging.

Ideal for: Professional touring, events of 200-500 people, medium-sized theaters, churches, live sound reinforcement systems where scalability is key.

Technical characteristics:

  • Amplification: D-Class, 2000 W Peak (1000 W Program / 500 W RMS)
  • Woofer: 10 inch, 2.5 inch coil
  • Treble Tweeter/Drivers: Six 2-inch arc compression drivers
  • Frequency response: 48 Hz to 18 kHz (±3 dB)
  • Maximum SPL: 130 dB peak
  • Coverage: Horizontal 120° constant, vertical 15° (expandable up to 90° in arrangement of up to 6 boxes)
  • Built-in DSP: 90 Hz High Pass Filter, Arrangement Modes (1-6 Boxes), Compatible with CDL18S/ULT18/AIR18S, Crossover 420 Hz, Limiter
  • Assembly: Integrated rigging for hanging, 35 mm pole socket with dual tilt (0° and -7.5°)
  • Dimensions: 38.1 × 43.1 × 40.6 cm (height × width × depth)
  • Gross weight (with packaging): 21.3 kg

Compatibility: Modular System: Chain CDL10P with other CDL10P, or combine with CDL12P in Line Array Array. Compatible with CDL18S, ULT18 or AIR18S subs. Direct balanced XLR input and output.
